Product Overview
Unmatched Durability and Performance
“Sullair portable air compressors offer robust performance and reliability for demanding environments. With advanced rotary screw technology, these machines ensure efficient operation and extended air end life.
– Proven reliability with durable materials
– Extended air end life with controlled lubrication
– Integrated inlet control for optimal performance”
Sullair air compressors feature asymmetrical rotors and a proven bearing design, ensuring long-lasting performance. Continuous improvements in materials and engineering enhance durability and efficiency.
Controlled pressure lubrication and bearing fluid reservoirs provide a consistent fluid supply to rotating elements, significantly extending the life of the air end and ensuring reliable operation.
The instrument panel offers dynamic fault display, multi-language options, and service reminders, enhancing usability and maintenance efficiency. Weatherproof design ensures reliable operation in diverse conditions.
AWF fluid is designed to handle heat, cold, and humidity, offering excellent lubrication and protection against oxidation and corrosion. It maximizes air/fluid separation and limits fluid carryover.
The in-line six-cylinder QSM11 engine offers reliable power with advanced electronic control, optimizing fuel injection for better performance, reduced emissions, and enhanced fuel economy.
Horsepower
280Working Weight
4500 kgLength
5969Actual Delivery m³/min (cfm)
25.5 (900)Rated Pressure bar (psi)
10.3 (150)Pressure Range min/max bar (psi)
4/10.3 (58/150)Fuel Consumption at Full Load l/h (gph)
41.3 (11)Noise Level dBA
85Maximum Operating Altitude m (ft)
4200 (13,780)Make & Model (Emissions Level)
DF Cummins QS B6.7-C260-34 (Stage III)Operating Speed rpm
200Horsepower
280Displacement l (in³)
6.7 (409)Cooling System Capacity l (gal)
9.4 (2.5)Engine Oil Capacity l (qts)
12 (12)Fuel Tank Capacity l (gal)
450 (119)Electrical System Voltage
24Battery Rating CCA
210Working Weight
4500 kgLength
5969Track Width mm (in)
2020 (79.5)Max Towing Speed kph (mph)
20 (12.4)Tire Pressure kPa (psi)
525 (76)Tire Size
215/75R16CWeight kg (lbs)
4500 (9920)Length x Width x Height mm
5517 x 2211 x 2518 (217 x 87 x 99)Track Width mm (in)
2000 (79)Max Towing Speed kph (mph)
20 (12.4)Tire Pressure kPa (psi)
850 (123)Tire Size
215/75R17.5Working Weight kg (lbs)
4500 (9920)Length x Width x Height mm (in)
3866 x 1760 x 2086 (152 x 69 x 82)
